300mm Tube Subwoofer
KSC-W1200T
RMSPOWER
PEAKPOWER
800W
200W
RMSPOWER
PEAKPOWER
1200W
200W
300mm Box Subwoofer
KSC-W1200B
300mm Subwoofer
KFC-W112S
Powered Subwoofer
KSC-SW11
MAXPOWER
150W
RMSPOWER
PEAKPOWER
1200W
300W
Low frequency output has been improved by increasing the cone area without changing the
cutout diameter. By adopting a “Stress-free Spider” and a “Thermal Efficient System” the
mechanical and thermal durability has also been improved dramatically delivering smooth
and strong bass sound with long lasting reliability.
Performance & Reliability
Oversized Cone
Stress-free Spider
Model
PEAK Power
RMS Power
Cone
Over Sized
Diaphragm
Impedance
Frequency Response
Mounting Depth
KFC-WPS1200F
1400W
350W Carbon-Glass Fibre Honeycomb Cone
-
4Ω
30Hz - 700Hz
100mm
KFC-WPS1000F
1000W
250W Carbon-Glass Fibre Honeycomb Cone
-
4Ω
35Hz - 800Hz
85mm
KFC-PS3016W
2000W
400W PP Cone with Square Array Pattern
•
4Ω
32Hz - 300Hz
131.6mm
KFC-PS2516W
1300W
300W PP Cone with Square Array Pattern
•
4Ω
32Hz - 300Hz
116.3mm
KSC-W1200T
1200W
200W
Injection PP Cone
-
4Ω
40Hz - 800Hz
-
KSC-W1200B
1200W
300W
Injection PP Cone
-
4Ω
38Hz - 300Hz
-
KFC-W112S
800W
200W
Injection PP Cone
-
4Ω
28Hz - 800Hz
138.6mm
KSC-SW11
Max Power
150W
-
Ribbed Aluminium Cone
-
-
50Hz - 125Hz
(Cutoff Frequency)
-
300mm Flat Subwoofer
300mm Subwoofer
KSC-WPS1200F
KFC-PS3016W
RMSPOWER
PEAKPOWER
1400W
350W
RMSPOWER
PEAKPOWER
2000W
400W
250mm Flat Subwoofer
KSC-WPS1000F
RMSPOWER
PEAKPOWER
1000W
250W
250mm Subwoofer
KFC-PS2516W
RMSPOWER
PEAKPOWER
1300W
300W
RMS
XR400-4
X501-1
X801-5
X301-4 KAC-9106D KAC-8406 KAC-7406 KAC-6406 KAC-5206 KAC-6104D
RMS Powerat 4Ω
Bridged 200W 300W
300W Bridged 150W 500W Bridged 200W Bridged 180W Bridged 130W Bridged 150W 200W
RMS Powerat 2Ω
500W
500W
1000W
300W
KFC-WPS1200F
350W
BEST
BEST
KFC-WPS1000F
250W
BEST
GOOD*
GOOD*
GOOD
KFC-PS3016W
400W
BEST*
KFC-PS2516W
300W
GOOD*
BEST
KFC-W112S
200W
BEST
KSC-W1200B
300W
BEST
KSC-W1200T
200W
BEST
GOOD
BEST
Note:
In order to obtain the best amplifier / speaker performance without failure even when according to the above chart:
1)
DO NOT raise the head unit’s volume to its fullest.
2)
DO NOT set the amplifier’s input sensitivity to its maximum, and always set it to match the combining head unit’s pre-out level.
If you do not follow these two rules, clipping signals will output from the amplifier which will result in speaker damage.
* Use of two subwoofers are recommended.
RECOMMENDED SYSTEM CHART
11
Speakers
SUBWOOFERS
